Product Description
The Performance 8W CNC Machine is built for precision, power, and versatility—making it the perfect solution for professional woodworkers, small manufacturers, and advanced hobbyists. With 4-axis capability and rotary machining support, this model handles complex cuts and detailed carving with ease.
Its rigid, all-welded steel frame, precision ball screws, and prismatic linear guides ensure smooth, accurate motion across all axes. The 3HP electro-spindle features integrated liquid cooling for consistent performance and quiet operation, even during extended use. The high-clearance gantry and millable MDF spoil board provide a true perpendicular cutting surface, essential for high-precision work.
Powered by the advanced iCNC Controller with a 15.6” touchscreen, onboard memory, and remote access via Android devices, the Performance 8W offers intuitive control and real-time toolpath visualization. Prewired for rotary kits and designed for demanding applications, this machine delivers industrial-grade results in a compact footprint.
Product Features
-
4-Axis Capability: Supports rotary machining for advanced 3D carving and complex cuts
-
Rigid Steel Frame: All-welded construction for maximum stability and durability
-
Precision Motion System: Prismatic linear guides and ball screw transmission on X, Y, and Z axes
-
High-Performance Spindle: 3HP water-cooled electro-spindle with ER20 collet system
-
Advanced Control Interface: iCNC Controller with 15.6” touchscreen and Android remote access
-
Rotary Ready: Prewired for rotary axis integration
-
Millable Spoil Board: MDF surface can be flattened for true perpendicular cutting
-
Quiet Operation: Liquid-cooled spindle reduces noise and wear
-
Compact Footprint: Ideal for workshops with limited space
-
Tool Touch-Off & Onboard Cooling: Included for enhanced accuracy and spindle longevity
Product Specifications
-
X Axis Travel: 24″ (610mm)
-
Y Axis Travel: 47.63″ (1210mm)
-
Z Axis Travel: 5.9″ (150mm)
-
Table Work Area: 24″ x 48″
-
Spindle Type: 3HP Water Cooled
-
Spindle Configuration: ER20 (1/4″ & 1/2″)
-
Controller: iCNC with 15.6” Touchscreen
-
On-Board Memory: Yes
-
Rapid Feed Rate: 300ipm (5m/min)
-
Tool Touch-Off: Included
-
Onboard Cooling: Included
-
Machine Base: Welded Steel
-
Rotary Axis: Yes (Prewired)
-
Resolution: ±0.00393″ (0.10mm)
-
Precision Linear Guides: X / Y / Z
-
Ball Screw Transmission: X / Y / Z
-
Power Requirements: 220V, 50-60Hz, 10A, 1-Phase
-
Working Table: High Rigidity Aluminum Extrusion
-
Gantry Bridge: High Rigidity Aluminum Extrusion
-
Gantry Supports: Aluminum Alloy Gravity Cast
-
Max Gantry Clearance: 6.5″ (165.1mm)
-
Clearance Above Spoil Board: 5.5″ (139.7mm)
-
Machine Dimensions: 62.99″ L x 37.36″ W x 30.27″ H
Product Documentation
Performance Series Owner's Manual
Training & Certification
We highly encourage new owners of these CNC machines to include the EMPOWER(ED) ACADEMY CNC training and certification materials for $999 USD. Intended for classroom instruction, the information in this course is invaluable for home hobbyists and enthusiasts as well. Get the most out of your CNC machine from the start by learning foundational skills in CAD/CAM/CNC!
