Mi-T-M Electric Air Compressors Simplex horizontal model - 23.5 @ 175, 7.5 HP, 80-gallon, ACS-20375-80H

The Mi-T-M ACS-20375-80H Simplex Horizontal Electric Air Compressor is engineered for reliable performance in commercial and industrial applications. Delivering 23.5 CFM at 175 PSI with a 7.5 HP motor and an 80-gallon ASME-certified receiver tank, this compressor ensures consistent airflow for pneumatic tools, production lines, and maintenance tasks.

Built with a high-quality two-stage pump and splash lubrication, the ACS-20375-80H provides long-lasting, smooth operation. The stainless-steel braided discharge hose and powder-coated ASME tank enhance durability, while the magnetic start with thermal overload protection safeguards the motor. An hour meter allows accurate tracking for routine maintenance.

Backed by a 1-year limited electric motor warranty and compliant with the ASME Boiler and Pressure Vessel Code – U, this horizontal compressor combines reliability, safety, and professional-grade performance.

Why Choose the Mi-T-M ACS-20375-80H Electric Air Compressor?

• Consistent Airflow – 23.5 CFM at 175 PSI supports a wide range of tools and industrial applications.

• Reliable Two-Stage Pump – Splash-lubricated design ensures smooth and long-lasting operation.

• Durable Construction – Stainless-steel braided hose and powder-coated ASME tank for superior longevity.

• Motor Protection – Magnetic start with thermal overload prevents motor damage.

• Easy Maintenance – Hour meter tracks run time for timely servicing.

• Industrial Compliance – Built to meet ASME Boiler and Pressure Vessel Code – U standards.

• Warranty Coverage – 1-year limited electric motor warranty for peace of mind.

Specifications

• Brand: Mi-T-M
• Model: ACS-20375-80H
• Type: Electric Air Compressor – Simplex Horizontal
• Air Delivery: 23.5 CFM @ 175 PSI
• Horsepower: 7.5 HP
• Tank Capacity: 80 Gallons (ASME-certified, powder-coated)
• Pump Type: Two-stage, splash-lubricated
• Hose: Stainless-steel braided discharge hose
• Start Type: Magnetic start with thermal overload protection
• Additional Features: Hour meter for usage tracking
• Compliance: ASME Boiler and Pressure Vessel Code – U certified
• Warranty: 1-year limited electric motor warranty
• Lead Time: 4 weeks
