Mi-T-M Electric Air Compressors Simplex horizontal model - 23.5 @ 175, 7.5 HP, 80-gallon, ACS-23175-80H

The Mi-T-M ACS-23175-80H is a high-capacity, industrial-grade electric air compressor designed for heavy-duty commercial and workshop applications. Delivering 23.5 CFM at 175 PSI with a 7.5 HP motor, this horizontal simplex unit provides consistent and reliable compressed air for tools, machinery, and large-scale operations.

Built for durability and long-term performance, the ACS-23175-80H features a quality two-stage compressor pump, splash lubrication, and a stainless-steel braided discharge hose for maximum reliability. Its powder-coated ASME-certified receiver tank ensures safe operation under high pressure, while magnetic start with thermal overload protection protects the motor and enhances lifespan.

Additional features include an hour meter to track maintenance intervals and a 1-year limited electric motor warranty. Certified to the ASME Boiler and Pressure Vessel Code – U, this compressor is ideal for workshops, industrial facilities, and commercial operations that require robust and continuous air supply.

Why Choose the Mi-T-M ACS-23175-80H Electric Air Compressor?

• High-Performance Output – 23.5 CFM at 175 PSI provides continuous air supply for heavy-duty tools and machinery.

• Durable Pump System – Two-stage compressor pump with splash lubrication for long-lasting reliability.

• Safe & Efficient Operation – ASME-certified tank with magnetic start and thermal overload protection.

• Rugged Construction – Powder-coated horizontal receiver tank built for industrial environments.

• Maintenance-Friendly – Equipped with an hour meter for tracking service intervals.

• Warranty & Certification – 1-year limited electric motor warranty and ASME-compliant for safety.

Specifications

• Brand: Mi-T-M
• Series: Simplex Horizontal Electric Air Compressors
• Model: ACS-23175-80H
• Type: Electric Air Compressor – Horizontal
• CFM: 23.5 @ 175 PSI
• Motor Power: 7.5 HP
• Compressor Pump: Two-stage, splash lubricated
• Discharge Hose: Stainless-steel braided
• Receiver Tank: 80-gallon, ASME-certified, powder coated
• Start Type: Magnetic start with thermal overload protection
• Maintenance: Hour meter included
• Warranty: 1-year limited electric motor warranty
• Certification: ASME Boiler and Pressure Vessel Code – U
• Lead Time: Approx. 4 weeks
