Mi-T-M Electric Air Compressors Simplex horizontal model - 34.2 @ 175, 10.0 HP, 120-gallon ADS-46310-120H

The Mi-T-M ADS-46310-120H is a heavy-duty, horizontal electric air compressor designed for industrial and commercial applications requiring high-capacity compressed air. With a 10.0 HP motor delivering 34.2 CFM at 175 PSI, this compressor provides consistent and reliable airflow for powering pneumatic tools, equipment, and machinery.

Built for durability and long-term operation, this unit features a quality two-stage pump with splash lubrication, a stainless-steel braided discharge hose, and a powder-coated ASME-certified receiver tank. The magnetic start with thermal overload protection ensures safe operation, while the hour meter allows easy monitoring of maintenance intervals.

Engineered to meet industry standards, the ADS-46310-120H is ASME Boiler and Pressure Vessel Code – U certified and comes with a 1-year limited electric motor warranty, making it a reliable choice for demanding work environments.

Why Choose the Mi-T-M ADS-46310-120H Air Compressor?

• High-Capacity Performance – 34.2 CFM at 175 PSI for powering multiple pneumatic tools simultaneously.

• Durable Pump System – Two-stage pump with splash lubrication for long-lasting performance.

• Industrial-Grade Construction – Powder-coated ASME-certified 120-gallon receiver tank.

• Safety Features – Magnetic start with thermal overload protection ensures safe operation.

• Reliable Monitoring – Hour meter for tracking maintenance intervals.

• Stainless-Steel Braided Discharge Hose – Enhanced durability and longevity.

• Warranty & Certification – 1-year limited electric motor warranty and ASME U-code compliance.

Specifications

• Brand: Mi-T-M
• Model: ADS-46310-120H
• Type: Electric Air Compressor – Horizontal Simplex
• CFM/PSI: 34.2 CFM @ 175 PSI
• Motor: 10.0 HP Electric
• Tank Capacity: 120 Gallons
• Pump: Two-stage, splash lubricated
• Hose: Stainless-steel braided discharge hose
• Frame/Finish: Powder-coated ASME receiver tank
• Start Type: Magnetic start with thermal overload protection
• Hour Meter: Included
• Certification: ASME Boiler and Pressure Vessel Code – U
• Warranty: 1-year limited electric motor warranty
• Lead Time: Approx. 4 weeks
