Mi-T-M Electric Air Compressors Simplex horizontal model - 46.5 @ 175, 15.0 HP, 120-gallon AES-23315-120H

The Mi-T-M AES-23315-120H Simplex Horizontal Electric Air Compressor is designed for high-demand industrial and commercial applications. Delivering 46.5 CFM at 175 PSI with a 15.0 HP motor and an ASME-certified 120-gallon receiver tank, this horizontal compressor provides consistent, reliable airflow for heavy-duty pneumatic tools and operations.

Equipped with a two-stage compressor pump with splash lubrication, it ensures smooth and long-lasting operation. The stainless-steel braided discharge hose and powder-coated ASME receiver tank provide superior durability. A magnetic start with thermal overload protection safeguards the motor, and the hour meter allows accurate tracking for scheduled maintenance.

Backed by a 1-year limited electric motor warranty and compliant with the ASME Boiler and Pressure Vessel Code – U, this compressor delivers professional-grade reliability you can trust.

Why Choose the Mi-T-M AES-23315-120H Electric Air Compressor?

• High-Performance Output – 46.5 CFM at 175 PSI for demanding industrial applications.

• Reliable Two-Stage Pump – Splash-lubricated for smooth, long-lasting performance.

• Durable Construction – Powder-coated ASME tank and stainless-steel braided hose ensure longevity.

• Motor Protection – Magnetic start with thermal overload safeguards your investment.

• Maintenance-Friendly – Hour meter provides accurate usage tracking.

• Industrial Safety – Built to meet ASME Boiler and Pressure Vessel Code – U standards.

• Warranty Coverage – 1-year limited electric motor warranty for peace of mind.

Specifications

• Brand: Mi-T-M
• Model: AES-23315-120H
• Type: Electric Air Compressor – Simplex Horizontal
• Air Delivery: 46.5 CFM @ 175 PSI
• Horsepower: 15.0 HP
• Tank Capacity: 120 Gallons (ASME-certified, powder-coated)
• Pump Type: Two-stage, splash-lubricated
• Hose: Stainless-steel braided discharge hose
• Start Type: Magnetic start with thermal overload protection
• Additional Features: Hour meter for usage tracking
• Compliance: ASME Boiler and Pressure Vessel Code – U certified
• Warranty: 1-year limited electric motor warranty
• Lead Time: 4 weeks
