Mi-T-M Electric Air Compressors Simplex horizontal model - 18.0 @ 175, 5.0 HP, 80-gallon ACS-23305-80H

The Mi-T-M ACS-23305-80H Electric Air Compressor delivers reliable, high-volume compressed air for industrial, commercial, and professional workshop applications. Engineered for consistent performance, this horizontal simplex two-stage compressor combines durability, efficiency, and user-friendly operation in a robust design.

With an 80-gallon powder-coated ASME receiver tank, stainless-steel braided discharge hose, and magnetic start for thermal overload protection, this compressor is built to handle demanding jobs while protecting both the motor and pump. The splash-lubricated two-stage pump ensures long-lasting, high-efficiency performance, while the integrated hour meter allows for easy maintenance tracking.

Why Choose the Mi-T-M Electric Air Compressor?

• High-Performance Pump: Two-stage, splash-lubricated compressor pump provides consistent airflow and pressure.

• Durable Construction: Powder-coated ASME receiver tank and stainless-steel braided discharge hose for longevity.

• Thermal Protection: Magnetic start prevents motor overload and ensures safe operation.

• Maintenance Friendly: Integrated hour meter tracks operating hours for timely maintenance.

• Industrial Compliance: ASME Boiler and Pressure Vessel Code – U certified for safety and reliability.

• Warranty: 1-year limited electric motor warranty.

Specifications

• Model: ACS-23305-80H
• Compressor Type: Horizontal Simplex
• Flow Rate: 18.0 CFM @ 175 PSI
• Horsepower: 5.0 HP
• Tank Capacity: 80 gallons
• Pump Type: Two-stage, splash-lubricated
• Hose: Stainless-steel braided discharge hose
• Frame: Powder-coated steel ASME receiver tank
• Protection: Magnetic start for thermal overload
• Maintenance: Hour meter included
• Certifications: ASME Boiler and Pressure Vessel Code – U
• Lead Time: 4 weeks
